Product Description
PASSION™ ED binoculars offer the perfect entry into the world of high-quality observation optics at an unbeatable price-performance ratio. The slim and ergonomic design has been combined with high-quality materials.
The entire housing is made of magnesium. Thanks to ED lenses, multi-coatings and matched optics, they offer a wide field of view, high edge-to-edge sharpness and transmission values, as well as a shorter close focus.
Their robustness and optical performance make them unique performers in their class. You will not find a comparably equipped binocular in this price range.
Technical Specifications
Prism type. Schmidt-Pechan
Magnification. 8x
Field of view (FOV) at 1.000y. 428
Field of view (FOV) at 1.000m. 143
Objective diameter (mm) Effective diameter 42
Ocular diameter (mm) Effective diameter 23,7
Exit pupil diameter (mm) Measurement of the pupillary ocular beam 5,25
Eye Relief (inches) From the last optical surface 0,7
Eye Relief (mm) From the last optical surface 18
Housing Main body and hinge magnesium
Close focus (feet) Shortest focal distance 5,9
Close focus (meters) Shortest focal distance 1,8
Interpupillary distance (IPD) Center pupil to centre pupil measurement 56 – 75
Dioptric compensation range . -2,5/+2,5
Waterproof Mbars /cm 100
Transmission Daylight ISO 14490-5:2005 90%
Height (inches) Without covers 2,26
Height (mm) Without covers 55
Weight (ounces) Without covers 26,1
Weight (grams) Without covers 740
Length (inches) At outside diameter 5,4
Length (mm) At outside diameter 138
Width (inches) Fully extended 5
Width (mm) Fully extended 127
Accessories are included with the purchase. instruction manual, cleaning cloth, hard
case, neoprene neck strap, hard case
strap, objective covers, ocular covers
