Sigma EVF-21 Electronic Viewfinder

Sigma EVF-21 Electronic Viewfinder

The Sigma EVF-21 Electronic Viewfinder brings clear, detailed eye-level composition to the Sigma FP2. Designed exclusively for the camera, it combines a 5.76-million-dot OLED display, a 90° tilting mechanism and an integrated eye sensor in a compact, lightweight accessory.

Whether you prefer shooting at eye level or composing from a lower viewpoint, the EVF-21 provides a comfortable, immersive way to frame your photographs and assess fine detail.

A Clear, Detailed View of Your Subject

The 0.5-inch OLED panel delivers approximately 5.76 million dots, providing a high-resolution view for checking composition and focus. Its bright display helps you concentrate on your subject, while approximately 100% frame coverage allows you to see the full image area as you compose.

With 0.88× magnification, measured using a 50mm lens focused at infinity at −1 dioptre, the EVF-21 offers a generous view that complements the FP2’s compact design.

Tilting Design for Flexible Composition

The viewfinder tilts upwards from 0° to 90°, giving you the freedom to adjust your viewing position to suit the shot. Use it straight on for conventional eye-level photography, or angle it upwards when working at waist level or from a lower viewpoint.

This flexibility makes it easier to explore different perspectives while maintaining the focused viewing experience of an electronic viewfinder.

Comfortable Viewing, Tailored to You

An integrated eye sensor adds convenience during use, while the −4.0 to +2.0 dioptre adjustment lets you tailor the viewfinder’s focus to your eyesight.

The approximately 19.5mm eye point provides viewing distance behind the eyepiece lens. Both the EC-51 standard eyecup and EC-61 large eyecup are supplied, allowing you to choose the fit that feels most comfortable. The larger eyecup also helps shield your eye from surrounding light.

Dedicated Connection for the Sigma FP2

Designed specifically for the Sigma FP2, the EVF-21 connects through the camera’s USB-C port and can be attached or removed as your shooting setup changes.

Weighing approximately 110g with the EC-51 eyecup fitted, it adds dedicated viewfinder functionality while keeping your equipment portable. A supplied VC-08A semi-hard case provides protection when the viewfinder is stored or carried separately.

Key Features & Specifications

• Compatibility: Designed exclusively for the Sigma FP2.

• Display: 0.5-inch OLED panel with approximately 5.76 million dots.

• Frame coverage: Approximately 100%.

• Magnification: 0.88× with a 50mm lens at infinity, −1 dioptre.

• Tilt adjustment: 0–90° upwards.

• Eye sensor: Integrated for convenient operation.

• Eye point: Approximately 19.5mm from the back of the eyepiece lens.

• Dioptre adjustment: −4.0 to +2.0.

• Connection: USB Type-C input.

• Dimensions: Approximately 50.2 × 77.8 × 62.1mm, including EC-51 eyecup.

• Weight: Approximately 110g, including EC-51 eyecup.

What’s in the Box

• Sigma EVF-21 Electronic Viewfinder

• EC-51 eyecup

• EC-61 large eyecup

• VC-08A semi-hard case
