Tascam DR-05XP Stereo Handheld Audio Recorder and USB Audio Interface

Tascam DR-05XP Stereo Handheld Audio Recorder & USB Audio Interface

32-Bit Float Portable Recording – Professional Audio Made Simple

The Tascam DR-05XP is a powerful yet easy-to-use handheld audio recorder designed for creators who need reliable, high-quality sound wherever they are. With 32-bit float recording, built-in stereo condenser microphones and one-handed operation, the DR-05XP removes the complexity from audio capture while delivering consistently clean, distortion-free results.

Ideal for musicians, videographers, podcasters, journalists, students and field recordists, the DR-05XP is equally at home recording music, dialogue, meetings, dictation and ambient sound. It also doubles as a 2-in / 2-out USB-C audio interface, making it a versatile studio and location recording tool.

Capture Perfect Audio Without Setting Levels

Thanks to 32-bit float recording, the DR-05XP captures an extremely wide dynamic range, eliminating clipping and distortion caused by incorrect input levels. Whether recording quiet dialogue or loud live sound, your audio is preserved accurately every time—no gain adjustment required.

Supported formats include 32-bit float, 24-bit and 16-bit WAV up to 96 kHz, as well as MP3, giving you flexibility for professional production or quick sharing.

Built-In Stereo Condenser Microphones

The integrated omnidirectional condenser microphones handle sound pressure levels up to 125 dB SPL, making them suitable for loud environments such as rehearsals, concerts and location sound recording. Clear stereo imaging ensures natural, immersive recordings straight out of the device.

Simple One-Handed Operation

Designed for fast, intuitive use, the DR-05XP allows you to start recording instantly with minimal setup. The backlit LCD screen provides clear visibility in all lighting conditions, while the compact body fits comfortably in the palm of your hand—perfect for handheld, tripod or camera-mounted use.

Portable Recorder and USB Audio Interface

More than just a field recorder, the DR-05XP functions as a USB-C audio interface, allowing you to record directly into audio software on Mac or PC. Use it as a USB microphone for voiceovers, streaming or remote work, or transfer files quickly via USB.

Ideal for Musicians and Creators

With built-in tools including a tuner, reverb, overdubbing and low-cut filters, the DR-05XP is a flexible solution for music practice, songwriting and demos. Four selectable low-cut filter settings help reduce unwanted rumble and background noise when recording on location.

For video creators, the Auto Tone output for cameras simplifies post-production, and tripod mounting makes integration into video rigs effortless.

Flexible Inputs and Expandability

In addition to the built-in microphones, the 3.5mm stereo mini-jack input supports external microphones with plug-in power or line-level sources. Record in mono or stereo to suit any situation, from interviews to ambient soundscapes.

Key Features

• 32-bit float recording for distortion-free audio without level setting

• Built-in stereo condenser microphones (up to 125 dB SPL)

• Records WAV (16-bit / 24-bit / 32-bit float) up to 96 kHz and MP3

• 2-in / 2-out USB-C audio interface for Mac and PC

• One-handed operation with backlit LCD screen

• External mic/line input with plug-in power

• Built-in speaker for quick playback

• Low-cut filters, tuner, reverb and overdubbing

• Compact, lightweight and tripod-mountable

Technical Specifications

Recording Media
microSD / microSDHC / microSDXC (up to 512 GB)

Recording Formats

• WAV: 44.1 / 48 / 96 kHz – 16-bit / 24-bit / 32-bit float

• MP3: 44.1 / 48 kHz – 32 to 320 kbps

Inputs / Outputs

• Mic / Line Input: 3.5mm stereo mini-jack (plug-in power supported)

• Headphone / Line Output: 3.5mm stereo mini-jack

• USB: USB-C (USB 2.0 High Speed)

USB Audio Interface

• 2 inputs / 2 outputs

• 44.1 / 48 kHz, 24-bit

Audio Performance

• Frequency response: 20 Hz – 20 kHz (44.1 kHz)

• THD+N: ≤0.01%

Power Supply

• 2 × AA batteries (alkaline or NiMH, not included)

• USB bus power

• Optional AC adapter (Tascam PS-P520U)

Dimensions
61 × 142 × 27 mm

Weight
174 g (with batteries) / 126 g (without batteries)

Operating Temperature
0°C to 40°C

Compact, Reliable and Ready Anywhere

Whether you’re recording music, capturing dialogue on location, creating content for video, or using it as a USB microphone, the Tascam DR-05XP delivers professional results with minimal effort. It’s a powerful, portable recording solution built for creators who want great sound—every time, everywhere.
