| White Balance |
|
| Settings |
AWB (Ambeince priority/White priority), Daylight, Shade, Cloudy, Tungsten light, White Fluorescent light, Flash, Custom, Colour Temperature Setting. White balance compensation: (1) Blue/Amber +/-9 (2) Magenta/ Green +/-9 |
| Custom White Balance |
Yes, 1 setting can be registered |
| White Balance Bracketing |
+/-3 levels in single level increments. 3, 2, 5 or 7 bracketed images per shutter release. Selectable Blue/Amber bias or Magenta/ Green bias |
| Memory Card |
|
| Memory Card Type |
1x CompactFlash Type I (UDMA 7 compatible) (Incompatible with Type II and Microdrive) 1x SD/SDHC/SDXC and UHS-I |
| Compatible Software |
|
| Compatible Software |
Canon: EOS Utility 3.5 or later (inc. Remote Capture ), Picture Style Editor, Map Utility, EOS Lens Registration Tool, EOS Web Service Registration Tool, Canon Camera connect app (iOS/ Android) |
| Image Processing |
|
| Maximum Recording Time |
4K and Full HD - Max duration 29min 59sec. (excluding High Frame Rate movies). No 4GB file limit with exFAT CF card |
| Software |
|
| Drivers |
Mac/Windows |
| Firmware Update |
Update possible by the user |
| Image Processing |
Digital Photo Professional 4.5 or later (RAW Image Processing) |
| Focusing |
|
| Select AF Point on Screen |
Transparent LCD in viewfinder and shown on Quick Control screen |
| AF Microadjustment |
Manual: Enter adjustment +/- 20 steps (wide and tele setting for zoom lenses). Adjust all lenses by same amount. Adjust up to 40 lenses individually. Adjustments remembered for lens by serial number |
| AF Working range |
EV -3 - 18 (at 23°C & ISO100) |
| Manual Focus |
Selected on lens |
| AF Assist Beam |
Emitted by an optional dedicated Speedlite |
| AF Lock |
Locked when shutter button is pressed half way or AF ON is pressed in One Shot AF mode. Using customised button set to AF stop in AI servo |
| AF Point Selection |
Automatic selection: All 61 point AF (based on EOS iTR AF setting) Manual selection: Single point AF (selectable points 61, 15, 9 or cross type only points selectable) Manual selection: Single point Spot AF Manual selection: AF point Expansion 4 points (up, down, left, right) Manual selection: AF point Expansion surrounding 8 points Manual selection: Zone AF (all AF points divided into 9 focusing zones) Manual selection: Large Zone AF (all AF points divided into 3 focusing zones) AF points can be selected separately for vertical and horizontal shooting |
| Type |
TTL-secondary image-forming phase-difference detection system with dedicated AF sensor |
| AF System |
61 Point / max of 41 cross-type AF points inc 5 dual cross type at f/2.8 and 61 points / 21 cross-type AF points at f/8. The number of cross-type AF points will differ depending on the lens (11) |
| AF Modes |
One Shot, AI Focus, AI Servo AF |
| File Types- Movie Size & Frame Rate |
|
| Movie Size & Frame Rate: Full HD |
(16:9) 1920 x 1080 (59.94, 50, 29.97, 25, 23.98 fps) intra or inter frame (16:9) 1920 x 1080 HDR ( 29.97, 25 fps) inter frame (16:9) 1920 x 1080 (29.97, 25) lite inter frame |
| Movie Size & Frame Rate: HD |
(16:9) 1280 x 720 (119.9, 100 fps) intra frame |
| Movie Size & Frame Rate: 4K |
(17:9) 4096 x 2160 (29.97, 25, 24, 23.98 fps) Motion JPEG (internal recording only) |
| Supported File Formats |
|
| Photos |
JPEG (EXIF compliant)/RAW (Canon .CR2 only) |
| Exposure |
|
| AE Lock |
Yes |
| AE Lock-auto: |
In One-shot AF mode with evaluative metering exposure is locked when focus is achieved. |
| AE Lock-manual: |
By AE lock button in P, Av, Tv and M modes |
| Histogram-brightness: |
Yes |
| Histogram-RGB: |
Yes |
| Auto Exposure Bracketing |
+/-3 EV in 1/3 or 1/2 stop increments |
| Metering Modes |
Approx. 150,000-pixel RGB+IR metering sensor, 252-zone metering. EOS Intelligent Subject Analysis system (1) Evaluative metering (linked to All AF point) (2) Partial metering (approx. 6.1% of viewfinder at centre) (3) Spot metering: Center spot metering (approx. 1.3% viewfinder at center) AF point-linked spot metering not provided (4) Center weighted average metering |
| Highlight Alert |
Yes |
| Metering Range |
EV 0 - 20 (at 23°C, ISO100, with evaluative metering) |
| Exposure Compensation |
+/-5 EV in 1/3 or 1/2 stop increments (can be combined with AEB). |
| ISO Sensitivity |
Auto 100-32000 (in 1/3-stop or whole stop increments) ISO can be expanded to L:50, H1: 51200, H2: 102400, |
| Shutter |
|
| Shutter Release |
Soft touch electromagnetic release |
| Shutter Type |
Electronically-controlled focal-plane shutter |
| Image Sensor |
|
| Low-pass Filter |
Built-in/Fixed |
| Sensor Cleaning |
EOS integrated cleaning system |
| Image Sensor Type |
36 x 24 mm CMOS |
| Colour Filter Type |
Primary Colour |
| Effective Pixels: Still Images |
Approx. 30.4 megapixels |
| File Types |
|
| RAW+JPEG Simultaneous Recording (Y/N) |
Yes |
| RAW+JPEG Simultaneous Recording Type |
any combination of RAW + JPEG possible, separate formats to separate cards possible |
| Image Size |
JPEG: 3:2 ratio (L) 6720x4480, (M1) 4464x2976, (S1) 3360x2240 , (S2) 1696x1280 , (S3) 640x480 4:3 ratio (L) 5952x4480, (M1) 3968x2976, (S1) 2976x2240 , (S2) 1920x1280 , (S3) 720x480 16:9 ratio (L) 6720x3776, (M1) 4464x2512, (S1) 3360x1888 , (S2) 1920x1080 , (S3) 720x408 1:1 ratio (L) 4480x4480, (M1) 2976x2976, (S1) 2240x2240 , (S2) 1280x1280 , (S3) 480x480 RAW: (RAW) 6720x4480, (M-RAW) 5040x3360, (S-RAW) 3360x2240 |
| Still Image Type |
JPEG: 3 compression options RAW: RAW, M-RAW, S-RAW and Dual Pixel RAW (14bit, Canon original RAW 2nd edition) Complies with Exif 2.30 and Design rule for Camera File system 2.0 Complies with Digital Print Order Format [DPOF] Version 1.1 |
| Viewfinder |
|
| Viewfinder Information |
AF information: Single/Spot AF points, AF Frame, AF status, Focus indicator, AF mode, AF point selection, AF point registration. Exposure information: Shutter speed, aperture value, ISO speed (always displayed), AE lock, exposure level/compensation, flash metering, spot metering circle, exposure warning, AEB, metering mode, shooting mode. Flash information: Flash ready, high-speed sync, FE lock, flash exposure compensation, red-eye reduction light. Image information: Card information, maximum burst (2 digit display), Highlight tone priority (D+), JPEG/RAW indicator, Dual Pixel RAW, Digital Lens Optimizer. Composition information: Grid, Electronic level. Other information: Battery check, Warning symbol, Flicker Detection, drive mode, white balance |
| Viewfinder Magnification |
Approx. 0.71x |
| Dioptre Correction |
-3 to +1 m-1 (dioptre) |
| Monitoring Panel |
|
| Brightness Adjustment |
Manual: Adjustable to one of seven levels. Color Tone Adjument: 4 settings |
| Screen Coating |
Anti-reflection and Anti-smudge. Reinforced glass incorporated |
| Display Options |
(1) Quick Control Screen (2) Camera settings (3) Dual Axis Electronic Level (4) Custom Quick Control Screen |
| Playback Display Formats |
(1) Single image (2) Single image with information (2 levels ) Basic - Shooting information (shutter speed, aperture, ISO and Image quality)Detailed - Shooting information (shutter speed, aperture, ISO, metering Image, quality and file size), Lens information , Brightness and RGB histogram, White balance, Picture Style, Color space and noise reduction, Lens optical correction, GPS information(3) 4 image index(4) 9 image index(5) 36 image index(6) 100 image index(7) Jump Display (1, 10 or 100 images, Date, Folder, Movies, Stills, Protected images, Rating)(8) Movie edit(9) RAW processing(10) Rating |
| Viewing Angle |
Approx 170° vertically and horizontally |
| Screen Type-touch Technology |
Capacitive type |
| Displayed Languages |
English, German, French, Dutch, Danish, Portuguese, Finnish, Italian, Norwegian, Swedish, Spanish, Greek, Russian, Polish, Czech, Hungarian, Romanian, Ukrainian, Turkish, Arabic, Thai, Simplified Chinese, Traditional Chinese, Korean and Japanese |
| Shooting |
|
| Intervalometer |
Built-in, number of shots selectable from 1-99 or unlimited. Bulb timer possible |
| Colour Space |
sRGB and Adobe RGB |
| Image Processing |
Highlight Tone Priority Auto Lighting Optimizer (4 settings) Long exposure noise reduction High ISO speed noise reduction (4 settings) Lens optical correction (3): - Peripheral illumination correction, Chromatic aberration correction (during/after still photo shooting, during Video only) - Distortion correction, Diffraction correction, Digital Lens Optimizer (during/after still photo shooting) Resize to M, S1, S2 or S3 (6) Cropping: JPEG images can be cropped (Aspect ratios 3:2, 4:3, 16:9, 1:1) - 45 cropping sizes selectable, from 11% to 95% (diagonal) - Switch between vertical and horizontal cropping orientation - Cropping frame can be moved using touch screen operation RAW image processing (7) Multiple exposure |
| Self Timer |
2 or 10 sec. |
| Drive Modes |
Single, Continuous High, Continuous Low, Silent single, Silent Continous High, Silent Continuous Low, Self timer (2s+remote, 10s+remote) |
| Continuous Shooting Speed |
Max. Approx. 7fps. with full AF / AE tracking, speed maintained for up to unlimited number of JPEGs or 21 RAW images (1) (2) (10) Max. 4.3fps in Live View mode with AF Tracking |
| Shooting Modes |
Scene Intelligent Auto, Program AE , Shutter priority AE, Aperture priority AE, Manual (Stills and Movie), Bulb and Custom (x3) |
| Picture Styles |
Auto, Standard, Portrait, Landscape, Fine Detail, Neutral, Faithful, Monochrome, User Defined (x3) |
| File Management |
|
| File Numbering |
(1) Consecutive numbering, (2) Auto reset, (3) Manual reset |
| Folders |
New folders can be manually created and selected |
| Image Erase/protection |
Single image, Selected images, Folder, Card |
| Image Metadata Tag |
User copyright information (can be set in camera) Image rating (0-5 stars) IPTC data (registered with EOS Utility) Image transfer with caption (Caption registered with EOS Utility) |
| Inputs/outputs |
|
| Microphone |
Yes |
| Viewfinder |
|
| Depth of Field Preview (Y/N) |
Yes |
| Depth of Field Preview Type |
with Depth of Field preview button |
| Eyepiece Shutter |
On strap |
| Eyepoint |
Approx. 21mm (from eyepiece lens center) |
| Live View Mode |
|
| Focusing: Auto |
Dual Pixel CMOS AF (Face Detection and Tracking AF, FlexiZone - Single, FlexiZone - Multi), available with all EF lenses and Touch shutter |
| Focusing: Manual Focus |
Magnify the image 5x or 10x at any point on screen |
| Display Options |
4 levels available through INFO. button: No information, Basic shooting information, Advanced shooting information and Advanced shooting information with Histogram Multiple Exposure status also available in Multiple Exposure mode |
| Metering |
Real-time evaluative metering with image sensor (315-zone) Partial metering (approx. 6.3% of Live View screen) Spot metering (approx. 2.7% of Live View screen) Center-weighted average metering Active metering timer can be changed |
| Coverage |
Approx. 100% (horizontally and vertically) |
| Flash |
|
| Flash Exposure Bracketing |
Yes |
| Flash Exposure Bracketing Compatibility |
with compatible External Flash |
| External Flash Control |
via camera menu screen |
| Flash Exposure Compensation |
+/- 3EV |
| Flash Exposure Compensation Increment |
in 1/3 increments |
| Flash Exposure Compensation Types |
with EX series Speedlites |
| Hot Shoe |
Yes |
| Pc Terminal |
Yes |
| External Flash Compatibility |
E-TTL II with EX series Speedlites, wireless multi-flash support |
| Flash Exposure Lock |
Yes |
| Modes |
E-TTL II Auto Flash, Metered Manual |
| X-sync |
1/200sec |
| Second Curtain Synchronisation |
Yes |
| Physical Specifications |
|
| Operating Humidity Range |
85% or less humidity |
| Operating Temperature Range |
0 – 40 °C |
| Product Weight |
800 g |
| Product Depth |
75.9 |
| Product Height |
116.4 |
| Product Width |
150.7 mm |
| Product Dimensions (WXHXD) |
Approx. 150.7 x 116.4 x 75.9 mm |
| Water/dust Resistance |
Yes |
| Body Materials |
Magnesium Alloy body and polycarbonate with glass fiber Prism cover |
| General Features |
|
| Intelligent Orientation Sensor |
Yes |
| Playback Zoom |
1.5x - 10x in 15 steps |
| LCD Panel |
Yes |
| Illumination |
Yes |
| Slide Show: Repeat |
On/Off |
| Slide Show : Image Selection |
All images, by Date, by Folder, Movies, Stills, Protected images or Rating |
| Slide Show: Playback Time |
1/2/3/5/10 or 20 seconds |
| Sound Memo (Y/N) |
No |
| Data Verification |
Erase protection of Single image, Folder or Card |
| Power Source |
|
| Battery Indicator |
6 levels + percentage |
| Battery Life |
Approx. 900 shots (at 23°C) Approx. 850 (at 0°C) |
| Power Saving |
Power turns off after 1, 2, 4, 8, 15 or 30mins. |
| Power Requirements |
Rechargeable Li-ion Battery LP-E6N (supplied) / LP-E6 |
| Power Supply & Battery Chargers |
Battery charger LC-E6E (supplied), Battery charger LC-E6, AC Adapter AC-E6N and DC Coupler DR-E6, AC Adapter Kit ACK-E6N/ACK-E6, Car Battery Charger CBC-E6 |
| Image Processor |
|
| Type |
DIGIC 6+ |
| Operating System Compatibility |
|
| OS |
Windows |
| Version |
Windows 7 (excl. Starter Edition) Windows 8 and Windows 10
OS X v10.7-10.11 |
| Lens |
|
| Lens Mount |
EF (excludes EF-S / EF-M lenses) |
| Recording |
|
| Time-lapse Movie |
Sequence of images between 2 and 3600 shots, up to 2min. 24sec. (PAL)/Shooting interval can be set between 1 sec. to 99 hr. 59min. 59 seconds |
